2022 Hot Automatic Complete Sparkling Water Bottling Line
Complete Carbonated Soft Drinks Bottling Plant
*We supply complete solution for the carbonated drinks bottling plant ,including Water treatment system / Carbonated beverage mixing system / Washing filling capping machine / Code sprayer / Pasteurizer tunnel / Automatic labeling machine / Automatic packing machine / Automatic Palletizer system
| Technical parameter: Carbonated Drink Bottling Machine | |||||
| Model | DCGF14-12-5 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 | DCGF40-40-12 |
| Capacity(for 500ml) | 2000-3000 | 3000-5000 | 5000-7000 | 8000-10000 | 12000-15000 |
| Suitable bottle shapes | PET circular | ||||
| Bottle diameter(mm) | Dia50-Dia115mm | ||||
| Bottle height (mm) | 160-320mm | ||||
| Filling type | Isobaric filling | ||||
| Filling pressure | <0.4 Mpa | ||||
| Rinsing water pressure | >0.06Mpa <0.2Mpa | ||||
| Application | carbonated drinks bottling plant | ||||
| Total power (KW) | 4.4kw | 5.2kw | 6.2kw | 7.5kw | 8.2kw |
| Overall dimensions | 2.5*1.9m | 2.8*1.9m | 3.2*2.2m | 3.4*2.5m | 4.8*2.3m |
| Height | 2.3m | 2.5m | 2.5m | 2.5m | 2.5m |
| Weight(kg) | 3000kg | 4500kg | 6000kg | 8500kg | 10000kg |
