Auto Hot Melt Glue Carton Box Flaps Folding Sealing Gluing Machine
Box Folding Case Sealer Carton Folder Hotmelt Carton Sealer
The Automatic Hot Melt gluing machine is manually adjustable to suit a range of carton sizes. The GPC-50D simultaneously glues the top and bottom flaps of uniform size cartons. Multiple different gluing programs give trouble-free sealing of a wide range of cardboard boxes.
| Model | GPC-50D Hot Melt gluing |
| Conveyor speed | 18m/min |
| Carton Max Size | L200×W150×H150mm |
| Carton Min Size | L600×W500×H500mm |
| Power Supply | 110/220V 50/60Hz 1Phase |
| Power | 400W |
| Adhesive Tape Width | 48/60/75mm |
| Air Consumption | 50NL/min |
| Air Compressing | 0.6Mpa |
| Table Height | 600+150mm |
| Machine dimension | L1770×W850×H1520mm |
| Machine weight | 250kg |
