Autoamtic Aluminum Pet Can CSD Carbonated Energy Drink Filling Seaming Canning Machine

Hits: 286

Details

Top Quality Sauce / Ketchup Can Filling And Sealing Machine Canning Equipment Production Line
* we provide the complete pop cans / tin can filling and package solution ,from can depalletizer ,can rinsing machine ,can filling & sealing monoblock machine ,leakage check,liquid nitrogen dosing machine ,pasteurizer tunnel ,blow dryer ,carton package ,film package system ,which is widely used for the beverage ,beer ,juice industry and so on

Technical parameter :ketchup can filling and sealing machine
Model	Gdf12-1	Gdf18-4	Gdf24-4	Gdf32-6	Gdf40-8
Capacity(cans/hour)	2000	8000	12000	15000	20000
Suitable bottle shapes	Pop can / tin can / pet can
Can diameter(mm)	Dia50 ~ dia99mm
Can height (mm)	70-133mm
Compressor air	Isobaric filling / normal pressure filling
Application	ketchup can filling and sealing machine
Total power (kw)	2.4kw	4.4kw	5.2kw	6.2kw	7.2kw
Overall dimensions	2.5*1.9m	2.8*1.9m	3.2*2.15m	3.5*2.5m	3.8*2.8m
Height	2.3m	2.5m	2.5m	2.5m	2.5m
Weight(kg)	2500kg	3200kg	4000kg	4500kg	6500kg

Different filling capacities
GDF12-1 can filling and seaming machine capacity:1500-2000 bottles per hour.
GDF18-4 can filling and seaming machine capacity:6000-8000 bottles per hour.
GDF24-4 can filling and seaming machine capacity:9000-10000 bottles per hour.
GDF32-6 can filling and seaming machine capacity:12000-15000 bottles per hour.
GDF40-8 can filling and seaming machine capacity:18000-20000 bottles per hour.
