Carton sealing
XD-FX5050
Tape sealing equipment for assembled shipping cartons. Compare carton dimensions and tape width before selecting the sealing setup.
*Catalogue specification; box sample confirmation required.
MACHINE FEATURES
The XD-FX5050 is designed for the packaging operations described below. Compare its working dimensions and features with your box drawing and production requirements.
The listed tape-width range applies to this catalogue model. Confirm the tape specification, sealing-head setup and overlap on the carton with a sample before ordering consumables.
Match the listed working height to the upstream and downstream conveyors. Review the carton transfer points and available floor space before agreeing the installation layout.
This model seals assembled shipping cartons. Actual throughput depends on carton size, handling and the surrounding line, so assess it with the cartons and packing arrangement you plan to use.
This model seals assembled shipping cartons. Actual throughput depends on carton size, handling and the surrounding line, so assess it with the cartons and packing arrangement you plan to use.
TECHNICAL DATA
Confirm the machine configuration against your carton sample, required output and site power supply.
Confirm your configuration| Catalogue speed | 800–1,000 boxes / hour |
|---|---|
| Finished box length | 130 mm minimum; no upper limit listed |
| Finished box width | 140–500 mm |
| Finished box height | 130–500 mm |
| Catalogue electrical supply | 220 V / 50 Hz |
| Total power | 180 W motor |
| Machine net weight | Approx. 120 kg |
| Machine dimensions | 1,800 × 820 × (1,100–1,500) mm |
Figures are from the 2025 Xunding catalogue. Actual output depends on box design, cardboard and configuration. Confirm the current specification, electrical supply and box sample before ordering.
BOX REQUIREMENTS
Share the drawing, dimensions and board specification.
The catalogue range is a starting point, not a fit guarantee.
Finished dimensions, blank drawing and a photo of the assembled box.
Cardboard type and thickness, and any printing or coating requirements.
Required boxes per hour, shift pattern and available space on the packing line.
Installation country, site electrical supply and commissioning requirements.
Review the box drawing and material against this model’s catalogue specification.
Box design exampleERECTING & TAPE SEALING
A shipping carton is opened for packing and then sealed. Carton erecting and tape sealing are separate operations from making a fruit tray. Select equipment around the carton style and the packing-line sequence.
View box requirements & modelsFREQUENTLY ASKED QUESTIONS
Send the finished-box dimensions, the flat blank drawing and cardboard thickness. Xunding must confirm the exact box structure and configuration; dimensions alone do not establish compatibility.
The catalogue output is 800–1,000 boxes per hour. Production speed depends on the carton design, material and machine settings. Send a box sample to discuss the expected output.
The catalogue lists 220 V / 50 Hz. Tell us your site voltage, phase and frequency before requesting a quote. Suitability and any required changes need confirmation for the installation site.
Include the XD-FX5050 model reference, box dimensions, board thickness, required output and destination. If you do not have a final drawing, describe the packaging you are working on.
REQUEST A QUOTATION
Tell us your box dimensions, cardboard and production target.
